Gas Hot Plates · CE

Name: SWENZA Gas Hot Plates · CE
Brand: SWENZA

12" – 36" · 8.5 kW per burner

CE-approved version of our countertop hot plates with flame-failure protection, set up for European gas families.

Certification

3 models

CP-UHP12CP-UHP24CP-UHP36

Request a quotation WhatsApp

Key features

Tap + to add an individual model to your inquiry list. Imperial and metric values as published in our catalog.

Model	Gas Type	Burners	Total kW	Overall Dimensions	Net Weight	Package Size	Shipping Weight
CP-UHP12	G20 / G30/G31	2	17	30.4×72.8×33cm	25 kg	40×85×44cm	38 kg
CP-UHP24	G20 / G30/G31	4	34	60.9×72.8×33cm	43.5 kg	70×85×44cm	62 kg
CP-UHP36	G20 / G30/G31	6	51	91.4×72.8×33cm	62 kg	100×85×44cm	86 kg

For commercial installation only; not intended for household use.
3/4" NPT rear gas connections. Inlet pressure as below: G20 at 20mbar-I2H.I2EandI2E+ G30/G31 at 30mbar-I3B/P(30) G30 at 28-30mbar G31 at 37 mbar -I3+(28-30-37)
An adequate ventilation system is required for Commercial Cooking Equipment
6" clearance required at both sides and rear from combustible construction.
